1006 hydraulic bridge
  • Price:Enquiry
  • Min. Order:100
  • Port:Qingdao
  • Production Capacity:
  • Payment Terms:
  • Type:
  • Application:
  • Material:
  • Usage Method:
  • Customized:
Min. Order:100
Port:Qingdao
Production Capacity:
Payment Terms:
Type:
Application:
Material:
Usage Method:
Customized:

Basic Information
Certification:Trademark:
Swecices:Specification:
Side effect:HS Code:
Usage:Sample:
Delivery Time:Origin:China
Package:
Certification:
Swecices:
Side effect:
Usage:
Delivery Time:
Package:
Trademark:
Specification:
HS Code:
Sample:
Origin:China

Based on the mature technology of 1000, 800 and 600 series hydraulic bridge, the company launched the 1006 series hydraulic bridge, which is suitable for the harvester with full load of 8-13 tons. The product not only inherited all the advantages of the original hydraulic bridge, but also improved the design of the gearbox, achieving the advantages of compact structure, strong load capacity and so on, and greatly improved the reliability.
详细资料
平均输入功率 58KW 产 品 特 点
挡位设置 两挡



1、为客户提供整机、传动、液压、动力的匹配最优一体化解决方案,使整机底盘性能最优;

2、整机结构紧凑,可靠性高,故障率几乎为零;

3、两挡设置,操纵简单、方便舒适,节省油料20%,收割效率提高30%以上;

4、采用啮合套或同步器换挡机构,换挡平顺,无顿挫感;

5、铸件全部采用球墨铸件材料;

6、齿轮、轴套全部采用与汽车齿轮相同的材料、加工及热处理工艺,保证了使用性能;

7、齿轮全部延用1000系列变速箱的齿轮模数,传递扭矩大大增强;

8、轴承、油封全部采用国际知名品牌;

9、按照整机性能要求,可以适当调整传动速比;

10、按照客户的需求,可以实现两驱、四驱、防打滑功能。



换挡机构 啮合套/同步器
工作挡速比 变速箱:14.24、11.66
轮边减速器:5.42、6、5.86、7.727
行走挡速比 变速箱:4.19、4.55、4.94、5.8
轮边减速器:5.42、6、5.86、7.727
行驶速度 工作挡:0-10Km/h
行走挡:0-25Km/h
系统最高压力 42MPa
马达接口尺寸 定位孔:φ127,4-M14螺栓,分布圆φ161.9
液压件匹配 根据整机要求,合理匹配泵、马达型号,品牌可选配
轮距 根据整机参数而定
承载能力 整机满载8-13吨
适配机型 玉米机、青储机等自走式收获机械
