2000 hydraulic bridge
  • Price:Enquiry
  • Min. Order:100
  • Port:Qingdao
  • Production Capacity:
  • Payment Terms:
  • Type:
  • Application:
  • Material:
  • Usage Method:
  • Customized:
Min. Order:100
Port:Qingdao
Production Capacity:
Payment Terms:
Type:
Application:
Material:
Usage Method:
Customized:

Basic Information
Certification:Trademark:
Swecices:Specification:
Side effect:HS Code:
Usage:Sample:
Delivery Time:Origin:China
Package:
Certification:
Swecices:
Side effect:
Usage:
Delivery Time:
Package:
Trademark:
Specification:
HS Code:
Sample:
Origin:China

In order to fill the gap of drive axle for large harvester in China, the company developed 2000 series hydraulic drive axle on the basis of 1000 hydraulic axle, which is suitable for 15-30 ton harvester.  The product has three gears, which can adapt to a variety of complex working conditions and has strong driving ability.  Using hydraulic power disc brake, braking performance is better.
详细资料
平均输入功率 50KW 产品特点
挡位设置 三挡

1、 把机械、液压、电控技术进行合理匹配,避免简单的改制。

2、 整机结构紧凑,可靠性高,故障率低。

3、 三挡设置,操纵简单、方便舒适。

4、采用啮合套或同步器换挡机构,换挡平顺,无顿挫感。

5、铸件全部采用QT450-10材料,承载能力大大增强。

6、齿轮、轴套全部采用与汽车齿轮相同的材料、加工及热处理工艺,保证了使用性能。

7、全部采用加大模数的齿轮,传递扭矩大大增强。

8、轴承、油封全部采用国际知名品牌。

9、按照整机性能要求,可以适当调整传动速比。

10、按照客户的需求,可以实现两驱、四驱、防打滑功能。

11、根据客户的要求,做好整机匹配计算,输出底盘最佳方案,保证整机的速度特性、牵引特性、制动特性、效率特性达到最优。

换挡机构 啮合套/同步器
一挡速比 变速箱:12
轮边减速器:11.5
二挡速比 变速箱:6.3
轮边减速器:11.5
三挡速比 变速箱:2.8
轮边减速器:11.5
系统最高压力 42MPa
马达接口尺寸 定位孔:φ127,4-M14螺栓,分布圆φ161.9
液压件匹配 根据整机要求,合理匹配泵、马达型号,品牌可选配
重量 变速箱:235Kg
轮边减速器:280Kg
轮距 根据整机参数而定
承载能力 整机满载15-30吨
适配机型 玉米机、籽粒机、采棉机等自走式收获机械
